Chapter 6: LPC11U3x/2x/1x NVIC
8 GINT0 GPIO GROUP0
interrupt
-
9 GINT1 GPIO GROUP1
interrupt
-
13 to 10 - Reserved
14 SSP1 SSP1 interrupt Tx FIFO half empty
Rx FIFO half full
Rx Timeout
Rx Overrun
15 I2C I2C interrupt SI (state change)
16 CT16B0 CT16B0 interrupt Match 0 - 2
Capture 0 -1
17 CT16B1 CT16B1 interrupt Match 0 - 1
Capture 0 -1
18 CT32B0 CT32B0 interrupt Match 0 - 3
Capture 0 - 1
19 CT32B1 CT32B1 interrupt Match 0 - 3
Capture 0 -1
20 SSP0 SSP0 interrupt Tx FIFO half empty
Rx FIFO half full
Rx Timeout
Rx Overrun
21 USART USART interrupt Rx Line Status (RLS)
Transmit Holding Register Empty (THRE)
Rx Data Available (RDA)
Character Time-out Indicator (CTI)
End of Auto-Baud (ABEO)
Auto-Baud Time-Out (ABTO)
Modem control interrupt
22 USB_IRQ USB_IRQ interrupt USB IRQ interrupt
23 USB_FIQ USB_FIQ interrupt USB FIQ interrupt
24 ADC ADC interrupt A/D Converter end of conversion
25 WWDT WWDT interrupt Windowed Watchdog interrupt (WDINT)
26 BOD BOD interrupt Brown-out detect
27 FLASH Flash/EEPROM
interface interrupt
-
28 - - Reserved
29 - - Reserved
30 USB_WAKEUP USB_WAKEUP
interrupt
USB wake-up interrupt
31 IOH IOH interrupt I/O Handler interrupt
Table 59. Connection of interrupt sources to the Vectored Interrupt Controller
…continued
Interrupt
number
Name Description Flags
