Chapter 3 Maintenance Mode Functions and Operations
3-88
3.4.3.4 TEST PATTERNS
Press the MAINTENANCE button, select TEST PATTERNS with the Up and Down buttons, and
then press the OK button.
Parameter
Description
Remark
VERTICAL STRIPES
Vertical stripes
HORIZONTAL STRIPES
Horizontal stripes
CHECKERBOARD
Checkerboard
GRID,1-DOT LINE
Grid with line width of 1 dot
SOLID COLOR
Solid color pattern
GRADATION
Gradation pattern
MEDIA ADV ACCURACY
Pattern to measure the media advance accuracy
LINE WIDTH CHECK
Pattern to measure the line width
Parameter
Description
Remark
PRINT
Print the test pattern.
MODE
Select the print mode.
SMART PASS
Configure the smart pass setting.
Normally,
set it on.
DIRECTION
Select between bidirectional and unidirectional printing.
LENGTH
Define the print length.
NO OF SHEETS
Define the number of sheet.
K
Select whether or not print the pattern with the K color.
C
Select whether or not print the pattern with the C color.
M
Select whether or not print the pattern with the M color.
Y
Select whether or not print the pattern with the Y color.
Lc
Select whether or not print the pattern with the Lc color.
Lm
Select whether or not print the pattern with the Lm color.
Gy
Select whether or not print the pattern with the Gy color.
MAINTENANCE
 TEST PATTERNS ◎
