1.3.4 Printer heater section
The printer is equipped with three heaters to fix ink on the print media and stabilize the print
quality.
(27)
Preheater
(28)
Printheater
(29)
Afterheater
* These three heaters are controlled individually.
Figure 1.5 Heater names and locations (sectional view)
Note
Be careful about the hot surfaces of the heaters.
(29)
(27)
(28)
Media
