5.3.2 Waste ink bottle related messages
<Description>
Possible causes are as follows.
- No waste ink bottle is installed to the printer.
- The sensor for checking the waste ink bottle is defective.
- The harness, connectors, or boards connected to the sensor above are defective.
<Action>
Check the Items to be Checked on the table below, and perform the actions starting from the top
until the problem is solved.
No
Items to be Checked
Action
1
A waste ink bottle is installed
If no waste ink bottle is installed, install it.
2
Waste ink bottle sensor (see 6.11.2
MICRO SWITCH 4(WASTE INK
BOTTLE ASSY))
Check that the waste ink bottle is fixed securely. Then on
the operation panel’s MONITOR menu, select WASTE
BOTTLE and set INSTALLED.
Check that the switch operation is correct.
3
Waste ink bottle sensor’s connector
Remove the connector, and then re-connect it.
Then on the operation panel’s MONITOR menu, select
WASTE BOTTLE and set INSTALLED.
Check that the switch operation is correct.
4
Connection of the CN22 connector
on PCB-ASSY-ACT3
Remove the connector, and then re-connect it.
Then on the operation panel’s MONITOR menu, select
WASTE BOTTLE and set INSTALLED.
Check that the switch operation is correct.
5
Connection of the
CABLE(TU-SENS1)-ASSY(MW)
and
CABLE(TU-SENS2)-ASSY(MW)
cables.
Remove the connectors, and then re-connect them. Then
on the operation panel’s MONITOR menu, select WASTE
BOTTLE and set INSTALLED.
Check that the switch operation is correct.
6
PCB-ASSY-ACT3
Replace the PCB-ASSY-ACT3 board. Then on the
operation panel’s MONITOR menu, select WASTE
BOTTLE and set INSTALLED.
Check that the switch operation is correct.
7
PCB-ASSY-IPB5-100
Replace the PCB-ASSY-IPB5-100 board. Then on the
operation panel’s MONITOR menu, select WASTE
BOTTLE and set INSTALLED.
Check that the switch operation is correct.
INSTALL
WASTE INK BOTTLE
