Chapter 1 Overview of Maintenance Workflow
1-2
1.2 Necessary Tools
The tables 1-1 to 1-3 show the tools, measuring instruments, jigs, and consumables necessary
for maintenance operations.
Table 1-1 Tools and measuring instruments
Name
Quantity
Remarks
Phillips screwdriver (2 bits)
1
Commercially available
Phillips screwdriver (1 bit)
1
For removing the encoder, commercially
available
Torque screwdriver (2 bits)
1
For mounting the head unit (15 kgf·cm),
commercially available
Phillips screwdriver (long)
1
－
Stubby Phillips screwdriver (2 bits)
1
Commercially available
Flat-head screwdriver
1
For removing E-rings, commercially available
Flat-head screwdriver (short)
1
－
Flat-head precision screwdriver
1
For removing E-rings, commercially available
Hexagon button wrench
1
Size: 5, 6
Wrench
1
Size: 13
Pliers or long-nose pliers
1
For mounting E-rings, commercially available
Nipper
1
Commercially available
Multimeter
1
For measuring voltage, commercially available
Metal rule
1
For adjusting the head unit (300 mm or longer),
commercially available
Thickness gauge
1
0.2 to 0.5 mm
Tube cutter
1
Commercially available
Cutter knife
1
Commercially available
Cable tie
1
Commercially available
Microscope with scale
(M830-S or equivalent)
1
Peak staff microscope
Thermohygrometer
1
100x, No. 2008-100 (Scale: standard)
USB drive for rewriting engine firmware
ROM
1
For checking the printer installation environment,
commercially available, compatible USB 2.0
