1.5 Maintenance Space
Figure 1.12 shows space required for the printer maintenance.
Figure 1.12 Maintenance space
CIS: 6100
LCIS: 6400
1000
2000
1500
1500
3940
2200 in the vertical direction
(Unit: mm)
(Front side)
