Chapter 3 Maintenance Mode Functions and Operations
3-66
3.4.2.3 PH VOLTAGE OFFSET
Enter an offset value for the print heads voltage.
Press the ADJUST button, select PH VOLTAGE OFFSET with the Up and Down buttons, and
then press the OK button.
Select CC_P : ±X.XV with the Up and Down buttons, and then press the OK button.
CC : Print head color
P : Print head right or left
X.X : Current offset value
CC : Print head color
P : Print head right or left
±X.X : Current value
±Y.Y : Value after change
Select a digit to modify with the Right and Left buttons, and modify the digit's value with the Up
and Down buttons.
After the value has been modified, press the OK button.
Press the CANCEL button to return to the previous screen without modifying the value.
Note
The offset value is saved in the print heads.
>>PH VOLTAGE OFFSET CC_P
 ±X.X  ±Y.Y V ◎
>PH VOLTAGE OFFSET
 CC_P : ±X.XV ◎
ADJUST
 PH VOLTAGE OFFSET ◎
