Chapter 3 Maintenance Mode Functions and Operations
3-47
3.4.2 ADJUST
3.4.2.1 BIDIR POSITION
(1) PRINT CHCK PATTERN
Press the ADJUST button, select BIDIR POSITION with the Up and Down buttons, and then
press the OK button.
Select PRINT CHCK PATTERN with the Up and Down buttons, and then press the OK button.
Select a pattern with the Up and Down buttons, and press the OK button to confirm the pattern to
print.
ALL PRINT MODES: Print a check pattern for all print modes.
1: DRA,FAST PR,PRO*: Print a check pattern for draft, fast production, and production print modes.
2: STD & QUALITY: Print a check pattern for standard and quality print modes.
3: HIGH QUALITY: Print a check pattern for high quality print mode.
4: MAX QUALITY: Print a check pattern for max quality print mode.
Print the bidirectional position adjustment patterns and set adjustment values.
* With the LCIS model:
1: FAST PRO, PRO: Print a check pattern for fast production, and production print modes.
(a) PRINT PATTERN
Select PRINT PATTERN with the Up and Down buttons, and then press the OK button.
Press the OK button to display the print confirmation screen, then press the OK button again to
start printing.
>>>ALL PRINT MODES
EXECUTE OK? ◎
>>>ALL PRINT MODES
PRINT PATTERN ◎
>>PRINT CHCK PATTERN
ALL PRINT MODES ◎
>BIDIR POSITION
PRINT CHCK PATTERN ◎
ADJUST
BIDIR POSITION ◎
To Next Page
