Oki IP-6620 - 5.5.54 System Error 320 X: Head Drive Voltage Error

OKI Data Infotech Corporation CONFIDENTIAL
Chapter 5 Troubleshooting (Engine Section and USB Controller Section)
5-142
5.5.54 System Error 320X: Head Drive Voltage Error
<Description>
The head drive voltage is not the expected voltage.
X
Print Head No.
0
Print head 1
1
Print head 2
2
Print head 3
3
Print head 4
4
Print head 5
5
Print head 6
6
Print head 7
<Faulty part>
(1) HEAD CABLE, MW
(2) PCB-ASSY-HCB1M
(3) PCB-ASSY-IPB5-100
(4) Carriage cable (FFC): CARRIAGE FFC, MW
(5) Robot cable: ROBOT CABLE, MW
(6) INKJET HEAD,MW (print head)
<Action>
Check the Items to be Checked on the table below, and perform the actions starting from the top
until the problem is solved.
Note:
For this error, be sure to perform the actions 1 to 5.
No
Items to be Checked
Action
1
The width of the V-shaped folded part
on the PCB-ASSY-HCB1M-side FFC
Check that the width of the V-shaped folded part on the FFC
is proper. If not, adjust it. For the adjustment procedure, see
6.8.4 PCB-ASSY-HCB1M.
2
FFC’s external damage
Check the following to ensure that the FFC is not damaged.
- FFC’s terminal is detached from its base.
- FFC’s edges have not been abraded by friction.
If the FFC is damaged, replace it.
3
FFC’s connector connection
Reconnect the FFC on both the PCB-ASSY-HCB1M side
and the PCB-ASSY-IPB5-100 side.
If the cable terminals are smeared, softly wipe them with a
soft cloth or lint-free paper dampened with ethanol before
connecting them.
4
Robot cable’s connector connection
Reconnect the robot cable on both the PCB-ASSY-HCB1M
side and PCB-ASSY-ACT3 side.
Before connecting, check that the connector terminals and
cable connection part are not disconnected. If a connection
failure is found, replace the robot cable.
