Oki IP-6620 - 5.5.29 System Error 230 X: Suction Fan Error

OKI Data Infotech Corporation CONFIDENTIAL
Chapter 5 Troubleshooting (Engine Section and USB Controller Section)
5-109
5.5.29 System Error 230X: Suction Fan Error
<Description>
The suction fan is not rotating.
X
Suction fan.
0
Suction fan 1
1
Suction fan 2
2
Suction fan 3
3
Suction fan 4
<Faulty part>
(1) FAN4 (suction fan)
(2) PCB-ASSY-ACT3
(3) CABLE(SFAN)-ASSY(MW)
<Action>
Check the Items to be Checked on the table below, and perform the actions starting from the top
until the problem is solved.
No
Items to be Checked
Action
1
Suction fan’s operation
Unload the media from the printer, turn the printer on, and
enter the maintenance mode.
From the ACTUATORS menu, operate the suction fan motor
causing the error, and check the fan’s operating sound.
2
Suction fan’s harness condition
Check that the harness condition is proper as follows.
- The connectors are connected securely.
- The cable is not disconnected.
- The harness is not pinched by other parts.
- The cable jacket is not damaged.
3
Suction fan
Replace the suction fan motor causing the error.
4
PCB-ASSY-ACT3
Replace the PCB-ASSY-ACT3.
