5.5.36 System Error 250X: Media Heater Thermistor Error
<Description>
The heater thermistor read value is:
- -20°C or less; or
- 200°C or more
X
Media Heater
1
Preheater
2
Printheater
3
Afterheater
<Faulty part>
(1) PCB-ASSY-ACT3
(2) PCB-ASSY-IPB5-100
(3) For 2501: Supply-side paper guide
(4) For 2503: Take-up side paper guide
(5) For 2502: Platen
(6) CABLE(Thermistor)-ASSY(MW)
<Action>
Check the Items to be Checked on the table below, and perform the actions starting from the top
until the problem is solved.
No
Items to be Checked
Action
1
Thermistor’s harness condition
Check that the harness condition is proper as follows.
- The connectors are connected securely.
- The cable is not disconnected.
- The harness is not pinched by other parts.
- The cable jacket is not damaged.
2
Thermistor
Replace the whole unit including the thermistor causing the
error.
3
PCB-ASSY-ACT3
Replace the PCB-ASSY-ACT3.
4
PCB-ASSY-IPB5-100
Replace the PCB-ASSY-IPB5-100.
