Oki IP-6620 - 5.5.39 System Error 253 X: Media Heater Error (No interrupt)

OKI Data Infotech Corporation CONFIDENTIAL
Chapter 5 Troubleshooting (Engine Section and USB Controller Section)
5-121
5.5.39 System Error 253X: Media Heater Error (No interrupt)
<Description>
No heater sequence interruption is generated.
X
Media Heater
1
Preheater
2
Printheater
3
Afterheater
<Faulty part>
(1) FUSE
(2) CABLE(TRC-CTL)-ASSY(MW)
(3) CABLE(ACT-IPB-IF)-ASSY(MW)
(4) PCB-ASSY-TRC-MW
(5) PCB-ASSY-ACT3
(6) PCB-ASSY-IPB5-100
<Action>
Check the Items to be Checked on the table below, and perform the actions starting from the top
until the problem is solved.
No
Items to be Checked
Action
1
Power supply voltage
Check that the voltage supplied from the socket used for the
heaters is between 200 V and 240 V.
2
Fuse condition
Check that the fuse has not blown. Check the condition of the
harness connected to the fuse to confirm that the connectors
are properly connected.
3
Heater’s harness condition
Check that the harness condition is proper as follows.
- The connectors are connected securely.
- The cable is not disconnected.
- The harness is not pinched by other parts.
- The cable jacket is not damaged.
4
CABLE(TRC-CTL)-ASSY(MW)
condition
Check that the cable condition is proper as follows.
- The connectors are connected securely.
- The cable is not disconnected.
- The cable is not pinched by other parts.
- The cable jacket is not damaged.
5
Cable between the ACT3 and
IPB5
Reconnect the CABLE(ACT-IPB-IF)-ASSY(MW) to the ACT3
and the IPB5.
6
PCB-ASSY-TRC-MW
Replace the PCB-ASSY-TRC-MW.
7
PCB-ASSY-ACT3
Replace the PCB-ASSY-ACT3.
8
PCB-ASSY-IPB5-100
Replace the PCB-ASSY-IPB5-100.
