Chapter 5 Troubleshooting (Engine Section and USB Controller Section)
5-122
Important points when checking the harness connected to the fuse
Check that the contact is inserted completely so that the metal part of the contact is visible.
If the metal part is not visible, hold the wire and insert the contact as far as it goes so that the
contact’s metal part is visible.
The metal part of the contact must be visible.
Hold this part and insert the contact completely.
To Next Page
