OKI Data Infotech Corporation CONFIDENTIAL
Chapter 5 Troubleshooting (Engine Section and USB Controller Section)
5-115
5.5.33 System Error 2340: Capping Unit Sensor Error
<Description>
The capping unit sensor status does not change.
<Faulty part>
(1) MICRO SWITCH 4 (capping unit sensor)
(2) MOTOR(CAP)-UD (capping unit up/down motor)
(3) PCB-ASSY-ACT3
(4) CABLE(CAP-IF)-ASSY(MW)
<Action>
Check the Items to be Checked on the table below, and perform the actions starting from the top
until the problem is solved.
No
Items to be Checked
Action
1
Harness condition
Check that the harness condition is proper as follows.
- The connectors are connected securely.
- The cable is not disconnected.
- The harness is not pinched by other parts.
- The cable jacket is not damaged.
2
Capping unit sensor
Enter the maintenance mode, and from the actuators menu
operate the motor.
If the cap operates up and down, replace the sensor.
3
Capping unit up/down motor
Replace the motor.
4
PCB-ASSY-ACT3
Replace the PCB-ASSY-ACT3.
