3.4.2.2 MECHANICAL ADJUST
This menu is used to print the print head position adjustement pattern and to set adjustment
values for the print head positions and right and left alignment.
(1) PH POSITION ADJUST
Press the ADJUST button, select MECHANICAL ADJUST with the Up and Down buttons, and
then press the OK button.
Select PH POSITION ADJUST with the Up and Down buttons, and then press the OK button.
Select PRINT PATTERN with the Up and Down buttons, and then press the OK button.
(a) PRINT PATTERN
Press the OK button to display the print confirmation screen, then press the OK button again to
start printing.
You may press the CANCEL button to interrupt the printing.
>>PH POSITION ADJUST
EXECUTING...
>>PH POSITION ADJUST
EXECUTE OK? ◎
>>PH POSITION ADJUST
PRINT PATTERN ◎
>MECHANICAL ADJUST
PH POSITION ADJUST ◎
ADJUST
MECHANICAL ADJUST ◎
