Chapter 6 Parts Replacement (Disassembly/Reassembly)
6-12
6.3.10 COVER(PINCH-D)64-MW
<Removal>
1. Remove the COVER(PINCH-D)64-MW
and seven fixing screws.
6.3.11 COVER(SUBTANK)-MW
<Removal>
1. Remove the COVER(SUBTANK)-MW
with four fixing screws.
Note
Remove the COVER(SUBTANK)-MW while
holding it with your hand to prevent it from
falling.
COVER(PINCH-D)64-MW
COVER(SUBTANK)-MW
