1.4.4 Printer heater section
The printer is equipped with three heaters to fix ink on the print media and stabilize the print
quality.
(28)
Preheater
(29)
Printheater
(30)
Afterheater
* These three heaters are controlled individually.
Figure 1.10 Heater names and locations (sectional view)
Note
Be careful about the hot surfaces of the heaters.
(30)
(28)
(29)
Media
