Chapter 3 Maintenance Mode Functions and Operations
3-108
Path 4: Storing EEPROM data for backup in the flash memory (EEPROM Flash)
<Processing>
Stores all current system data in the EEPROM backup area of the flash memory.
<Operation and start timing>
(1) This is performed when the power is shut down.
(2) This storing operation can be performed with the maintenance mode's menu on the
operation panel.
- System menu: SAVE PRINTER SET.
Path 5: Restoring EEPROM backup data from the flash memory in EEPROM
(Flash EEPROM)
<Processing>
Writes all the EEPROM backup data saved in the flash memory into the EEPROM.
<Operation and start timing>
This restoration operation can be performed with the maintenance mode's menu on the
operation panel.
- System menu: LOAD PRINTER SET.
Note: Restart the printer after loading the settings.
Path 6: RAM EEPROM
Path 7: EEPROM RAM
Path 6 and Path 7 are used by the engine firmware as required.
