OKI Data Infotech Corporation CONFIDENTIAL
Chapter 5 Troubleshooting (Engine Section and USB Controller Section)
5-25
(LCIS model)
<Description>
The reservoir drawer is open.
If the error does not disappear after closing the reservoir drawer, there may be a problem with the
sensor.
<Action>
Check the Items to be Checked on the table below, and perform the actions starting from the top
until the problem is solved.
No
Items to be Checked
Action
1
Drawer connectors
Check that the connectors are correctly in contact when
the drawer is closed.
2
CABLE(LCISWei-Sen)-ASSY(MW)
replacement
Replace the harness if the connectors are damaged or
do not contact properly.
3
CABLE(LCISWei-Sen-IF)-ASSY(MW)
replacement
Replace the harness if the connectors are damaged or
do not contact properly.
CLOSE THE
RESERVOIR DRAWER
