Chapter 5 Troubleshooting (Engine Section and USB Controller Section)
5-44
<Action>
Check the Items to be Checked on the table below, and perform the actions starting from the top
until the problem is solved.
Upgrade the firmware to the latest version.
Connection of the harness
connector on the ambient
temperature thermistor
Check that the harness connector is securely connected to the
board’s connector.
Condition of the harness on
the ambient temperature
thermistor
Check that the harness condition is proper as follows.
- The cable is not disconnected.
- The harness is not pinched by other parts.
- The cable jacket is not damaged.
If a problem is found, replace the harness.
Ambient temperature
thermistor
Replace the part.
Note
The ambient temperature thermistor is fixed on the SUBTANK
BOX ASSY.
Replace the PCB-ASSY-ACT3.
Replace the PCB-ASSY-IPB5-100.
When the ambient temperature is low When the ambient temperature is high
<Description>
The ambient temperature where the printer is installed is 5°C or lower, or 35°C or higher.
<Action>
If the problem persists when the ambient temperature is between 5°C and 35°C, check the Items
to be Checked on the table below, and perform the actions starting from the top until the problem
is solved.
Upgrade the firmware to the latest version.
Connection of the ambient
temperature thermistor
harness
Check that the harness connectors are correctly connected to the
board connectors.
Condition of the ambient
temperature thermistor
harness
Check that the harness is not broken, trapped by other parts, or
damaged. Replace it if a problem is found.
Ambient temperature
thermistor
Replace the part.
Caution: The ambient temperature thermistor is secured to the
subtank unit.
Replace the PCB-ASSY-ACT3.
Replace the PCB-ASSY-IPB5-100.
To Next Page
