OKI Data Infotech Corporation CONFIDENTIAL
Chapter 5 Troubleshooting (Engine Section and USB Controller Section)
5-68
Error
No.
Cause
User Solution
Service Engineer Inspection
(For inspection criteria, see
Reference to Check/Replace
Parts.)
Assumed Replacement
Part
Reference to
Check/Replace
Parts
1500
PCB-ASSY-TRC-MW
Connection Error
Restart the printer.
Check the connection of
CABLE(TRC-CTL)-ASSY(MW).
- CABLE(TRC-CTL)-ASSY(MW)
- PCB-ASSY-TRC-MW
- PCB-ASSY-ACT3
- PCB-ASSY-IPB5-100
 5.5.9
1600
RSM Register Read/Write Error
Restart the printer.
Install the last firmware version.
- PCB-ASSY-IPB5-100
 5.5.10
1610
Flash Check Sum Error
Restart the printer.
ditto
- Firmware version
- PCB-ASSY-IPB5-100
 5.5.11
1620
PCB-ASSY-IPB5-100
Initialization Error
Restart the printer.
Install the last firmware version.
- PCB-ASSY-IPB5-100
 5.5.12
1630
Band Memory Read/write Error
Restart the printer.
ditto
ditto
 5.5.13
1640
USB Chip Register Read/write
Error (Peripheral)
Restart the printer.
ditto
ditto
 5.5.14
1641
USB Chip Register Read/write
Error (Host)
Restart the printer.
ditto
ditto
 5.5.14
1650
EEPROM Initialization Check
Error
Restart the printer.
Check the connection of
IC(EEPROM).
- IC(EEPROM)
- PCB-ASSY-IPB5-100
 5.5.15
1660
RSM Mask Memory Read/write
Error
Restart the printer.
Install the last firmware version.
PCB-ASSY-IPB5-100
 5.5.16
1670
ATG Register Read/write Error
Restart the printer.
ditto
ditto
 5.5.17
1700
ABC Register Read/write Error
Restart the printer.
ditto
ditto
 5.5.18
1800
PTG Register R/W Error
Restart the printer.
- Check the connection of
CARRIAGE FFC,MW connectors
on the HCB1M and the IPB5.
- Check the connection of ROBOT
CABLE,MW connectors
- CARRIAGE FFC,MW
- PCB-ASSY-HCB1M
- PCB-ASSY-IPB5-100
- ROBOT CABLE,MW
 5.5.19
1900
Power Supply Unit Error
(PCB-ASSY-ACT3 P12V)
Restart the printer.
- Check the connection of
CABLE(ACT-IPB-IF)-ASSY(MW).
- Check the connection of
CABLE(PSU-ACT)-ASSY(MW).
- Check the connection of
CABLE(PSU-ACT-IF)-ASSY(MW).
- PCB-ASSY-ACT3
- PCB-ASSY-IPB5-100
- Power supply unit (38V)
 5.5.20
1901
Power Supply Unit Error
(PCB-ASSY-ACT3 P24V)
Restart the printer.
ditto
ditto
 5.5.20
1902
Power Supply Unit Error
(PCB-ASSY-ACT3 P24VAR)
Restart the printer.
Check the connection of the
interlock switch connectors.
- Window sensor OKI Data
Infotech
- PCB-ASSY-ACT3
- Power supply unit (24V)
- PCB-ASSY-IPB5-100
 5.5.20
1903
Power Supply Unit Error
(PCB-ASSY-ACT3 P24VSF)
Restart the printer.
- Check the connection of
CABLE(ACT-IPB-IF)-ASSY(MW).
- Check the connection of
CABLE(PSU-ACT)-ASSY(MW).
- Check the connection of
CABLE(PSU-ACT-IF)-ASSY(MW).
- PCB-ASSY-ACT3
- PCB-ASSY-IPB5-100
- Power supply unit (38V)
 5.5.20
1905
Power Supply Unit Error
(PCB-ASSY-ACT3 P38V)
Restart the printer.
ditto
ditto
 5.5.20
1906
Power Supply Unit Error
(PCB-ASSY-ACT3 P38VAR)
Restart the printer.
Check the connection of the
interlock switch connectors.
- Window sensor OKI Data
Infotech
- PCB-ASSY-ACT3
- PCB-ASSY-IPB5-100
- Power supply unit (38V)
 5.5.20
1907
Power Supply Unit Error
(PCB-ASSY-ACT3 P38VAF)
Restart the printer.
- Check the connection of
CABLE(ACT-IPB-IF)-ASSY(MW).
- Check the connection of
CABLE(PSU-ACT)-ASSY(MW).
- Check the connection of
CABLE(PSU-ACT-IF)-ASSY(MW).
- PCB-ASSY-ACT3
- PCB-ASSY-IPB5-100
- Power supply unit (38V)
 5.5.20
1908
Power Supply Unit Error
(PCB-ASSY-IPB5-100
P38VAF)
Restart the printer.
ditto
ditto
 5.5.20
1909
Power Supply Unit Error
(PCB-ASSY-IPB5-100
P38VCRG)
Restart the printer.
- Check the connection of the
interlock switch connectors.
- Window sensor OKI Data
Infotech
- PCB-ASSY-ACT3
- PCB-ASSY-IPB5-100
- Power supply unit (38V)
 5.5.20
190a
Power Supply Unit Error
(ACT P36VARHCB)
Restart the printer.
ditto
ditto
 5.5.20
1a00
Carriage Power Error (CRG
P38VAF)
Restart the printer.
- Check the connection of
CARRIAGE FFC,MW connectors
on the HCB1M and the IPB5.
- Check the connection of ROBOT
CABLE,MW connectors.
- ROBOT CABLE,MW
- CARRIAGE FFC,MW
- PCB-ASSY-HCB1M
- PCB-ASSY-IPB5-100
 5.5.21
1a01
Carriage Power Error (CRG
PREF)
Restart the printer.
ditto
ditto
 5.5.21
1a02
Carriage Power Error (CRG
P1.2V)
Restart the printer.
ditto
ditto
 5.5.21
1a03
Carriage Power Error (CRG
P3.3V)
Restart the printer.
ditto
ditto
 5.5.21
