OKI Data Infotech Corporation CONFIDENTIAL
Chapter 5 Troubleshooting (Engine Section and USB Controller Section)
5-168
<Adjustment values for mechanical and print head adjustments>
- Correcting the cap position: See section 7.4.
- CAPPING-UNIT-CV Cam Position Adjustment:
- Adjusting the wiping position: See section 7.5.
- Nozzle position adjustment: See the User's Guide.
- Head position adjustment (main scan direction): See the User's Guide.
- Bidirectional adjustment: See the User's Guide.
- Media advance adjustment: See the User's Guide.
- Sensor adjustment (top): See the User's Guide.
- Sensor adjustment (side): See the User's Guide.
- Print head R/L adjustment: See the User's Guide.
(f) Perform the following in the SYSTEM menu in the maintenance mode on the operation
panel.
- SAVE DEFAULT SET.: Saves EEPROM data in the factory default setting area of the
flash memory.
- SAVE PRINTER SET.: Saves EEPROM data in the backup area of the flash memory.
(g) Restart the printer.
Notes
 When replacing the IPB5 board, turn off the power without executing fill cap. Note that the fill
cap status in the new IPB5 board is set as not being performed yet.
 After replacing the IPB5 board, update the firmware to the latest version.
