OKI Data Infotech Corporation CONFIDENTIAL
Chapter 6 Parts Replacement (Disassembly/Reassembly)
6-
26
4.
Pull the
ARM(PINC
H)
form the
front side,
remove the tab, and then re
move the
ARM(PINCH).
5.
Remove the
ROLL
ER(PINCH)MW
from
the
ARM(PINC
H) tabs.
HOLDER(PIN
CH)
T
ab
ARM(PINCH)
ROLLER(PINCH
)MW
ARM(PINCH)
T
abs
ROLLER(PINCH
)MW
