OKI Data Infotech Corporation CONFIDENTIAL
Chapter 6 Parts Replacement (Disassembly/Reassembly)
6-46
4. Pull the
POWER-BOX-CASE-MW-BOTTOM
completely toward you, rotate the fuse
holder counter-clockwise, and remove
the fuse.
5. Replace the fuse with the one with the
specification below.
- Rated specifications: 15 A, 250 V AC
- Speed characteristic: Time delay
- Fuse size: ⌀6.35 mm x 31.8 mm
Note
Use only fuses specified by OKI Data Infotech.
If a fuse outside the specified specification is installed, it may blow immediately or cause an
accident like a fire or electrical shock.
