Chapter 6 Parts Replacement (Disassembly/Reassembly)
6-73
<Assembly>
Note
The two extremities of the FFC-ADJ are different, one is for the PCB-ASSY-ADJ1 and the other
for the PCB-ASSY-HCB1M.
FFC-ADJ
For PCB-ASSY-ADJ1
For PCB-ASSY-HCB1M
Position 1
Position 2
Position 3
Position 4
Position 1
Position 2
Position 3
Position 4
Position 5
