OKI Data Infotech Corporation CONFIDENTIAL
Chapter 7 Adjustment
7-37
18. Open the drawer and install the reservoir.
19. Install the PIPE-BU-ASSY and secure it
with one screw.
20. Install the filter module and secure it with
one screw.
PIPE-BU-ASSY
Filter module
Securing screw
