Chapter 3 Maintenance Mode Functions and Operations
3-14
4: MAX QUALITY
(some menus are omitted below)
Nozzle mapping configuration (system firmware ver. 3.00 and later)
Smart nozzle mapping (before system firmware ver. 3.00)
Enter Lc
#01
#02
#03
#04
#05
#06
#07
#08
#09
#10
Enter Lm
#01
#02
(some menus are omitted below)
(some menus are omitted below)
Mechanical adjustment
Print head position adjustment
Print pattern
Feed media
Back feed media
Enter print head adjustment value
Lc
Lm
C
Y
M
Gy (with 7-color printers only)
Enter right and left adjustment value
Lc
Lm
(some menus are omitted below)
Nozzle position adjustment
Print pattern
Feed media
Back feed media
Enter Lc
Enter Lm
(some menus are omitted below)
Print head slant check
Print pattern
Feed media
Back feed media
