(c) TUR SENSORS
This menu diplays the conditions of the TUR unit sensors in real time.
The buzzer sounds when the conditions of the sensors change.
Select a sensor to display with the Up and Down buttons.
1/X is not displayed due to the number of displayed characters.
Sensor
Sensor value
TUR DRAWER R:
1: TUR unit is installed
TUR DRAWER L:
1: TUR unit is installed
SLACK UPPER LIMIT:
1: Upper limit (light passes through)
SLACK LOWER LIMIT:
1: Lower limit (light is blocked)
FUNCTION SWITCH 1:
1: Inner take-up selected
FUNCTION SWITCH 2:
1: Outer take-up selected
X: Sensor value (1/0)
Same for FUNCTION SWITCH 2
>>>TUR SENSORS
 FUNCTION SWITCH 1: X
>>>TUR SENSORS
 SLACK LOWER LIMIT: X
>>>TUR SENSORS
 SLACK UPPER LIMIT: X
>>>TUR SENSORS
 TUR DRAWER L: X
>>>TUR SENSORS
 TUR DRAWER R: X
