Oki IP-6620 - Page 9

OKI Data Infotech Corporation CONFIDENTIAL
Contents-6
5.9.1 Lithium battery problem............................................................................ 5-169
5.9.2 IC (EEPROM) .......................................................................................... 5-170
Chapter 6 Parts Replacement (Disassembly/Reassembly)
6.1 How to Read Disassembly/Reassembly Procedures .................................. 6-1
6.2 Part Names ................................................................................................. 6-2
6.2.1 Names and layout of parts ........................................................................... 6-2
6.3 Disassembling and Reassembling Exterior Parts ........................................ 6-3
6.3.1 COVER(FRONT)ASSY-MW ......................................................................... 6-3
6.3.2 COVER(L)ASSY-MW, and COVER(R)ASSY-MW ........................................ 6-4
6.3.3 COVER(Y-RAIL)-SL-MW, and COVER(Y-RAIL)-SR-MW ............................. 6-5
6.3.4 COVER(Y-RAIL)-64-MW .............................................................................. 6-6
6.3.5 COVER(R-L)-MW ........................................................................................ 6-7
6.3.6 COVER(SIDE-L)-MW ................................................................................... 6-8
6.3.7 COVER(SIDE-R)-MW .................................................................................. 6-9
6.3.8 FAN(REAR)ASSY MW ............................................................................... 6-10
6.3.9 OP-PANEL-UNIT-MW .................................................................................6-11
6.3.10 COVER(PINCH-D)64-MW ......................................................................... 6-12
6.3.11 COVER(SUBTANK)-MW ............................................................................ 6-12
6.3.12 SWITCH(Interlock)-ASSY and SWITCH(COVER)-ASSY ........................... 6-13
6.3.13 Photo sensor LG248NL1 ............................................................................ 6-15
6.3.14 FAN(REAR)ASSY MW ............................................................................... 6-16
6.3.15 CASE(CUTTER) and SLIDER(CUTTER) ................................................... 6-17
6.4 Disassembling and Reassembling the Y Driver ......................................... 6-18
6.4.1 Y DRIVE MOTOR and DRIVING PULLEY ................................................. 6-18
6.4.2 BELT(SUS) ................................................................................................ 6-22
6.4.3 Y-TENSION-PULLEY ................................................................................. 6-24
6.4.4 ROLLER(PINCH) ....................................................................................... 6-25
6.4.5 T-FENCE ................................................................................................... 6-27
6.4.6 ROBOT CABLE, MW ................................................................................. 6-28
6.4.7 CARRIAGE FFC, MW ................................................................................ 6-31
6.5 Disassembling and Reassembling the X Driver ......................................... 6-34
6.5.1 X-MOTOR-ASSY (with PINION) ................................................................. 6-34
6.5.2 SUCTION FAN ........................................................................................... 6-38
6.5.3 PCB-ASSY-SNS1 (Front side) ................................................................... 6-39
