9. Adjustment item list Field Service Ver. 1.0 Jun. 2008
144
Adjustment / Setting
9. Adjustment item list
Replacement part/Service job
Adjustment/setting items
No
Replace paper feed roller Replace separation roller assy Change marketing area Install LCT Replace IU Replace PH unit
Service Mode
Machine
Printer
Area
Leading Edge Adjustment 1 (2)
Centering 2 (2) (3)
Feed Direction Adjustment 3 (1)
Scan
Area
ADF Adjustment: Zoom 4
ADF Adjustment: Feed 5
BK-S Adjustment: Zoom 6
BK-S Adjustment: Feed 7
Touch Panel Adjust 8
State Con-
firmation
Tabl e Nu m b e r 9
System
Re-entry of setting values 10
Serial Number 11
Counter Life Counter Clear 12 ❍❍
Image Process Adjustment
Gradation Adjust 13 ❍
Admin.
Firmware Version 14
Re-entry of Utility settings 15
Re-entry of Security Settings settings 16
Positioning exposure unit 17
PH skew adjustment 18 (1)
F/W upgrading 19 ❍
Remounting of RAMU board to the MFBU board 20
Replace transfer belt unit 21
