Olivetti d-Color MF201 Service Manual

Field Service Ver. 1.0 Jun. 2008 17. Malfunction code
313
Troubleshooting
17.5.55 C6401: Other troubles of scanner
17.5.56 C6704: Image input time out
Relevant parts
BCRU board (BCRUB)
Exposure unit
MFBU board (MFBUB)
Step Action
WIRING DIAGRAM
Control signal
Location (Electri-
cal component)
1
Check the connectors between BCRUB
and MFBUB for proper connection and cor-
rect as necessary.
——
2 Change BCRUB — —
3 Change MFBUB — —
4 Change exposure unit — —
Relevant parts
BCRU board (BCRUB)
Exposure unit
MFBU board (MFBUB)
Step Action
WIRING DIAGRAM
Control signal
Location (Electri-
cal component)
1
Check the connectors between BCRUB
and MFBUB for proper connection and cor-
rect as necessary.
——
2 Change BCRUB — —
3 Change MFBUB — —
4 Change exposure unit — —
d-Color MF201
Y109660-1 Sevice Manual
d-Color MF201
