17. Malfunction code Field Service Ver. 1.0 Jun. 2008
306
Troubleshooting
17.5.30 C3101: Fusing roller separation failure
17.5.31 C3201: Fusing motor failure to turn
17.5.32 C3202: Fusing motor turning at abnormal timing
Relevant parts
Fusing pressure roller retraction motor (M12)
Fusing pressure home sensor (PS38)
Printer control board (PRCB)
Fusing unit
Step Action
WIRING DIAGRAM
Control signal
Location (Electri-
cal component)
1
Check the M12 connector for proper
connection and correct as necessary.
——
2 PS38 I/O check, sensor check PRCB CN30-13 (ON) C to D-25
3 M12 operation check PRCB CN31-1 to 2 C to D-25
4 Change M12 — —
5 Change fusing unit — —
6 Change PRCB — —
Relevant parts
Fusing motor (M2) Printer control board (PRCB)
Step Action
WIRING DIAGRAM
Control signal
Location (Electri-
cal component)
1
Check the M2 connector for proper
connection and correct as necessary.
——
2
Check the loading status of the fusing unit
drive, and correct the error as necessary.
——
3
Check the fusing unit, PRCB for proper
connection and correct or change as
necessary.
——
4 M2 operation check
PRCB CN27-4 (REM)
PRCB CN27-7 (LOCK)
C to D-22
5 Change M2 — —
6 Change PRCB — —
d-Color MF201
Service Manual Y109660-1
d-Color MF201
