Olivetti d-Color MF201 Service Manual

Field Service Ver. 1.0 Jun. 2008 17. Malfunction code
289
Troubleshooting
17.2.11 P-27: Secondary transfer ATVC failure
Relevant parts
High voltage unit (HV)
Printer control board (PRCB)
Image transfer entrance guide
2nd image transfer assy
Transfer belt unit
Step Action
1
Check roller opposed to the 2nd image transfer roller is grounded.
Clean the joint or correct if necessary.
2 Check the image transfer entrance guide for proper installation and correct if necessary.
3
Check that the spring does not come off during the pressure operation of the 2nd transfer roller
and correct if necessary.
4
Check the contact at the joint of the 2nd image transfer assy and HV.
Clean the joint or correct if necessary.
5 Change the transfer belt unit.
6 Change HV.
7 Change PRCB.
d-Color MF201
Y109660-1 Sevice Manual
d-Color MF201
