Field Service Ver. 1.0 Jun. 2008 10. Service Mode
173
Adjustment / Setting
10.5.10 Software Switch Setting
A. Software Switch
B. List of the software switch settings
Functions • To change the status of each function by setting values (mode, bit, HEX) for soft
switch of the machine as necessary.
• Refer to the corresponding item on [Admin.] for the list of the soft switches available
of setting by the user (administrator).
See P.141
• For details of the software switch for fax settings, refer to the FK-507 service manual.
See P.20 of the FK-507 service manual.
Use
Setting/
Procedure
1. Call the Service Mode on the screen.
2. Touch [System Input] o [Software Switch Setting].
3. Touch [Mode Selection], and enter the mode number (three digit number) using the
10-key pad.
4. Touch [Bit Selection].
5. Set the cursor using [m] or [o] key, and set the bit with 0 or 1 on the 10-key pad.
(When setting in hexadecimal, press [HEX Selection], and enter on the 10-key pad
or A to F keys.)
6. Touch [Apply].
7. Touch [OK].
Mode
• Each parameter is expressed as a three-digit number.
Use the keypad to type in the value.
Bit
• The bits are the eight numbers that represent the parameter status.
By specifying a binary number (0 or 1) for each of the bits (0 through 7), set-
tings for each parameter can be specified.
HEX
• Specify a setting for each mode as a hexadecimal number (0 through 9 and A
through F). Bit setting “0011 0000” is expressed as the hexadecimal setting
“30.”
• Specify the status of each parameter by using either bits or hexadecimal val-
ues.
Mode Setting item Ref. page
000 • TSI, password, memory TX
001 • Dest. insert
002 • Report
003 • Broadcast TX result report
004 • Memory time
005 • Default country setting
006 (Not used)
007 • G3-1 non-selectable cassette
008 • G3-2 non-selectable cassette
009 • Network non-selectable cassette
010 • Report non-selectable cassette
011 (Not used)
012 (Not used)
013 • Automatically switch destinations, operation when INBOX forward fails
