19.3.9 Scanner system: distorted image
A. Typical faulty images
B. Troubleshooting procedure
A02EF4C515DA
ABCDE
ABCDE
ABCDE
ABCDE
ABCDE
Step Section Check item Result Action
1
Installation Machine is installed on a level sur-
face.
NO Reinstall.
2
Exposure unit Exposure unit is not installed pre-
cisely.
YES Reinstall.
3
The problem has been eliminated
through the checks of steps up to 2.
NO Change exposure unit.
