Olivetti d-Color MF201 Service Manual

Field Service Ver. 1.0 Jun. 2008 17. Malfunction code
307
Troubleshooting
17.5.33 C3301: Fusing cooling fan motor/ 1 failure to turn
17.5.34 C3302: Fusing cooling fan motor/ 2,3 failure to turn
Relevant parts
Fusing cooling fan motor (FM13) Printer control board (PRCB)
Step Action
WIRING DIAGRAM
Control signal
Location (Electri-
cal component)
1
Check the FM13 connector for proper
connection and correct as necessary.
——
2
Check the fan for possible overload and
correct as necessary.
——
3 FM13 operation check
PRCB CN31-4 (REM)
PRCB CN31-5 (LOCK)
C to D-26
4 Change FM13 — —
5 Change PRCB — —
Relevant parts
Fusing cover cooling fan motor (FM11) Printer control board (PRCB)
Step Action
WIRING DIAGRAM
Control signal
Location (Electri-
cal component)
1
Check the FM11 connector for proper con-
nection and correct as
necessary.
——
2
Check the fan for possible overload and
correct as necessary.
——
3 FM11 operation check
PRCB CN31-7 (REM)
PRCB CN31-8 (LOCK)
C to D-26
4 Change FM11 — —
5 Change PRCB — —
d-Color MF201
Y109660-1 Sevice Manual
