Field Service Ver. 1.0 Jun. 2008 4. Service tool
29
Maintenance
4. Service tool
4.1 Service material list
4.2 CE tool list
*1: Inquire of KMBT about the part number of compact flash in which the firmware data is
written.
Name Shape Material No. Remarks
Cleaning pad_________110pcs/1pack
Isopropyl alcohol
A02EF2C526DA
A00KF2C506DA
Tool name Shape Quantity Parts No. Remarks
PH window cleaning jig1AVGR05391U
PH window cleaning jig
pad
1AVGR05417G
Color chart 1
AVGR06936D#A3
11 x 17
Compact flash 1
*1
4038F2C557DA
4038F2C558DA
A02EF2C520DA
4037F2C601DA
Y109660-1 Sevice Manual
d-Color MF201
