Field Service Ver. 1.0 Jun. 2008 19. Image quality problem
329
Troubleshooting
19.3.8 Scanner system: skewed image
A. Typical faulty images
B. Troubleshooting procedure
A02EF4C514DA
AA
Step Section Check item Result Action
1 Original Original is skew. YES Reposition original.
2
Original glass Original glass is in positive contact
with the flat spring without being tilt.
NO Reinstall the glass.
Check the original loading posi-
tion.
3
Exposure unit Exposure unit is not installed pre-
cisely.
YES Reinstall.
4
The problem has been eliminated
through the checks of steps up to 3.
NO Change exposure unit.
d-Color MF201
Y109660-1 Sevice Manual
d-Color MF201
