Olivetti d-Color MF201 - Options

Field Service Ver. 1.0 Jun. 2008 6. Other
39
Maintenance
6.2.2 Cleaning parts list
39
PWBs
ADCU board (ADCUB) P. 8 6
40 MFBU board (MFBUB) P. 8 7
41 BCRU board (BCRUB) P. 8 9
42 Inverter board (INVB) P. 9 0
43
Motors
Transport motor (M1) P. 9 1
44 Color PC motor (M3) P. 9 2
45 Fusing motor (M2) P. 9 2
46 Fusing pressure roller retraction motor (M12) P. 9 3
47 Toner supply motor/CK (M7) P. 9 3
48 Toner supply motor/YM (M6) P. 9 4
49 Scanner motor (M201) P. 9 4
50
Clutches
Transfer belt pressure retraction clutch (CL3) P. 9 5
51 Developing clutch/K (CL4) P. 9 6
52 Tim. roller clutch (CL1) P. 9 7
53
etc.
IDC registration sensor/MK (IDCS/MK) P. 9 7
54 IDC registration sensor/YC (IDCS/YC) P. 9 7
55 Exposure lamp (FL201) P.100
56 Scanner drive wires P.102
No. Section Part name Ref. page
No. Section Part name Ref. page
1
Processing section
Transfer belt unit P.107
2 PH window P.107
3
Tray 1
Tray 1 feed roller P.108
4 Tray 1 separation roller P.108
d-Color MF201
Y109660-1 Sevice Manual
d-Color MF201
