Olivetti d-Color MF201 Service Manual

2. Product specifications Field Service Ver. 1.0 Jun. 2008
4
Outline
B. Functions
Types of original Sheets, books, and three-dimensional objects
Max. original size Book scanner A3 or 11 x 17
Max. original weight Book scanner Max. 2 kg
Multiple copies 1 to 999
Warm-up time
(at ambient tempera-
ture of 23 °C/73.4 °F
and rated source volt-
age)
*Without FK-507 and
EM-310
When the sub power switch is turned ON at any timing while the main power
switch remains ON for a predetermined period of time or more:
37 sec. or less (Monochrome print)
40 sec. or less (Color print)
When the sub power switch is turned ON immediately after the main power
switch is turned ON:
90 sec. or less (Monochrome print and Color print)
Image loss Copy Leading edge: 4.2 mm (3/16 inch),
Trailing edge: 3 mm (1/8 inch),
Rear edge: 3 mm (1/8 inch),
Front edge: 3 mm (1/8 inch)
PC Print Leading edge: 4.2 mm (3/16 inch),
Trailing edge: 4.2 mm (3/16 inch),
Rear edge: 4.2 mm (3/16 inch),
Front edge: 4.2 mm (3/16 inch)
First copy time
(Tray1 A4 or 8
1
/
2
x 11,
full size)
Monochrome print 10.0 sec. or less
Color print 13.5 sec. or less
Processing speed 92.4 mm/s Plain paper (monochrome, full color), OHP film
46.2 mm/s Thick 1, Thick 2, Thick 3,
Envelope, Label sheet
Copying speed for
multi-copy cycle
1-sided 20 copies/min (A4 or 8
1
/
2
x 11, plain paper)
2-sided 18 copies/min (A4 or 8
1
/
2
x 11, plain paper)
Fixed zoom ratios Full size x1.000
Reduction Metric area x0.500, x0.707, x0.816, x0.866
Inch area x0.500, x0.647, x0.772, x0.785
Enlargement Metric area x1.154, x1.224, x1.414, x2.000
Inch area x1.214, x1.294, x1.545, x2.000
Zoom ratios memory 3 memories
Variable zoom ratios u0.250 to u4.000 in 0.001 increments
Paper size Tray 1 Metric area B6S, A5, A5S, B5, B5S, A4, A4S, A3,
A3 Wide, 8K, 16K, 16KS, FLS,
A6S (Thick paper only)
Inch area 5-
1
/
2
x 8-
1
/
2
, 5-
1
/
2
x 8-
1
/
2
S, 7-
1
/
4
x 10-
1
/
2
,
7-
1
/
4
x 10-
1
/
2
S, 8-
1
/
2
x 11, 8-
1
/
2
x 11S,
8-
1
/
2
x 14, A3 Wide (12 x 18)
4 x 6 (Thick paper only)
Copy exit tray capacity Plain paper 250 sheets
Thick paper 10 sheets
OHP film 1 sheet
d-Color MF201
Service Manual Y109660-1
d-Color MF201
d-Color MF201

Olivetti d-Color MF201 Specifications
