Olivetti d-Color MF201 Service Manual

Field Service Ver. 1.0 Jun. 2008 10. Service Mode
261
Adjustment / Setting
B. Sensor Check (Scanner)
Symbol Panel display Part/signal name
Operation characteristics/
panel display
10
ADF
PS1 Empty See P.39 of the DF-612/SP-503/MS-501 service manual.
PS2 Width Sensor 1
PS3 Width Sensor 2
PS4 Width Sensor 3
PS5 Length Sensor 4
PS6 Length Sensor 5
PS8 Regist
PS7 Before Read
PS9 Eject/Reverse
PS10 Feed Open&Shut
BS
PS201 Home Sensor Home position sensor Out of home At home
PS205 Size reset S Original cover sensor Lowered Raised
PS202 18 degree 18 degree sensor
Less than
18 degree
18 degree
or more
PS203 Original Size Detection Original size detection sensor/1
Original not
loaded
Original
loaded
PS204
Original Size Detection
Opt.
Original size detection sensor/2
Original not
loaded
Original
loaded
d-Color MF201
Y109660-1 Sevice Manual
