Field Service Ver. 1.0 Jun. 2008 6. Other
49
Maintenance
8. Disconnect three connectors [1], and
remove the harness from the wire
saddle [2].
9. Remove the right front cover.
See P.41
10. Disconnect two connectors [1].
11. Remove five screws [1].
A02FF2C036DA
[1]
[2] [1]
A02EF2C071DA
[1]
A02EF2C072DA
[1]
[1]
d-Color MF201
Y109660-1 Sevice Manual
