Olivetti d-Color MF201 Service Manual

6. Other Field Service Ver. 1.0 Jun. 2008
78
Maintenance
2. Connect the flat cable [1] to the exposure unit.
(Refer to the following illustration for the cable routing.)
A02FF2C522DA
[1]
Take care in direction
of terminal
Align the marking with the edge surface of the
flat cable guide, and fix the position.
d-Color MF201
Service Manual Y109660-1
