Quantum Superloader 3 User Manual

Chapter 4 SuperLoader Operation
View Status Information
SuperLoader User’s Guide 91
Figure 64 LCD
Messages
Table 6 describes the meaning of each message.
Table 6 SuperLoader
Status
Magazines
L=
* The left magazine is present.
R=
* The right magazine is present.
Loader (DLT/SDLT Only)
ONLINE The SuperLoader is available for use.
OFFLINE The SuperLoader is not available.
Drive
ONLINE The drive is available for use.
OFFLINE The drive is not available for use.
Mode
Random The change mode is set to Random.
Sequential The change mode is set to Sequential.
Barcode Reader
* A bar code reader is present.
Magazines: L=* R=*
Loader: ONLINE
Drive: ONLINE
Mode: Random
Barcode Reader: *
SCSI ID 4
Magazines: L=* R=*
Mode: Random
Barcode Reader: *
DLT/
SDLT
LTO

Quantum Superloader 3 Specifications

General

Product Type	Tape Autoloader
Number of Tape Drives Installed	1
Number of Cartridge Slots	8
Tape Technology	LTO Ultrium
Data Compression Ratio	2:1
Native Capacity	12 TB
Compressed Capacity	24 TB
Interfaces	SAS
Humidity	20% to 80% non-condensing
Operating Temperature	10°C to 35°C
Supported Media	LTO-5, LTO-4
