Quantum Superloader 3 User Manual

Chapter 1 Introduction
Rear View
SuperLoader User’s Guide 7
Figure 6 Magazine
Blank
Rear View 1
The fans and connection ports are visible on the back of the SuperLoader
as illustrated in figure 7
for SuperLoader DLT, and in figure 8 for
SuperLoader LTO.
Figure 7 SuperLoader
DLT Rear View
AC power System cooling fan
Ethernet connection
SCSI connector
Power supply
cooling fan
AC power
switch

Quantum Superloader 3 Specifications

General

Product Type	Tape Autoloader
Number of Tape Drives Installed	1
Number of Cartridge Slots	8
Tape Technology	LTO Ultrium
Data Compression Ratio	2:1
Native Capacity	12 TB
Compressed Capacity	24 TB
Interfaces	SAS
Humidity	20% to 80% non-condensing
Operating Temperature	10°C to 35°C
Supported Media	LTO-5, LTO-4
