Appendix B Specifications
SCSI Specifications
250 SuperLoader User’s Guide
SCSI Specifications 2
The SuperLoader uses an LVD SCSI connection. SCSI connectors are
VHDCI SCSI connectors. All cables conform to SPI-4 (SCSI Parallel
Interface-4), Revision 7. Please refer to this document for more
information.
SCSI Cable and
Terminator
Requirements
2
If the SuperLoader is the last device on the SCSI bus you must attach a
terminator to the SCSI connector on the back panel of the SuperLoader.
There must be a terminator on each end of the SCSI bus. Typically, the
host adapter provides the front-end termination.
SCSI Cable Length2 LVD SCSI configurations have a maximum allowable bus length of 12 m.
To determine the cable length of the bus, measure the lengths of the SCSI
cables connecting each device to that bus and add those lengths together
for the total length. To that total length, add 16 inches (40.64 cm) for the
internal SCSI cable length. On an LTO system, the SCSI bus length is
23.5 inches (596.9 mm).
Ethernet 2
The remote management port is 10/100 BaseT.
