Chapter 2 Installation and Configuration
Rack Mounting the SuperLoader
20 SuperLoader User’s Guide
• The following parts shipped with the rack:
• Eight clip nuts
•Eight screws
Figure 11 Required
Parts for Installation
2 Install two clip nuts, 1.75 in. (44.45 mm) apart, onto each of the four
rails of the rack, making sure that you install each pair of clip nuts at
exactly the same level (see figure 12
).
Support brackets
Support bracket screws
Long SuperLoader
brackets (74-60604-01)
Short SuperLoader
brackets (74-60604-03)
(74-60605-01)
