Chapter 1 Introduction
Front View
SuperLoader User’s Guide 5
Table 1 LCD Panel
Function Keys
Status LEDs 1 The status LEDs show SuperLoader and drive status information. The
green
Ready LED shows ready status information, and the amber Fault
LED shows fault status information. A solid
Fault LED indicates an error,
and a blinking
Fault LED indicates a need for attention.
Power Switch 1 The power switch is a soft key, which means that if the SuperLoader is
moving any cartridges when you press the power switch, it finishes
moving them before powering off. Any other functions, such as writing
to a tape or performing a diagnostic, are interrupted and terminated
when you press the power switch. However, the SuperLoader attempts to
write cached data to tape before the unit powers down.
Magazines 1 The SuperLoader is equipped with one or two cartridge magazines (see
figure 5
). The magazines are removable and each magazine
accommodates up to eight cartridges. If your SuperLoader contains only
one magazine, a magazine blank is installed in the other magazine bay.
The handles on magazines and magazine blanks are removable and allow
you to configure any magazine or magazine blank to fit in either the left
or the right magazine bay.
The magazines store the tape cartridges and can also store the cleaning
cartridge. The magazines also contain the part of the robotics that moves
the cartridges inside the SuperLoader.
Function Key Description
Enter
Press to select an option
Escape
Press to return to the previous
menu, to move backwards on a
screen, or to abort an operation
 (Scroll Up)
Press to move up through a menu
or through the menu settings
 (Scroll Down)
Press to move down through a
menu or through the menu
settings
