Chapter 1 Introduction
Front View
SuperLoader User’s Guide 3
Front View 1
The mailslot, LCD, function keys, status LEDs, power switch, and left and
right magazines are visible on the front panel of the SuperLoader (see
figure 3
).
Figure 3 SuperLoader
Front View
Mailslot 1 The SuperLoader has a manual entry port, the mailslot, which you can
use to load or unload a single cartridge. To maintain security, the mailslot
can be password protected. You can insert a cartridge in the mailslot even
if both magazines are completely filled, so long as the tape drive itself is
empty. You can also pass a tape cartridge from the mailslot to the
magazine if the drive is full but the magazine is not.
Note: You should run an inventory from the host application after
using the mailslot. The mailslot is not directly available from
the host application.
Left magazine/blank
Mailslot
Status LEDs
Right magazine/blank
Power switch
LCD 4 Function keys
