Quantum Superloader 3 - Table 38 Error Code Field Descriptions

Appendix A Basic Information Logs
SuperLoader Logs
SuperLoader User’s Guide 233
Table 38 Error Code
Field Descriptions
Field Description
Recovery Action Defines what the SuperLoader will do based on the event that occurred.
• If the value is 0 the SuperLoader will continue operations since this is
typically a soft recoverable event, or an event that is just recording a
action for when the develop team is working on enhancements.
• If the value is other than 0, then you must reboot the SuperLoader in
order to recover from the event. The reboot will happen automatically.
Task ID Defines what firmware task was being performed at the time of the event.
Task ID in (Hex)
Description
00 System Timer
01 Servo
02 Picker
03 Magazine Left
04 Magazine Right
05 Magazine Up left
06 Magazine Up right
07 Loader
08 Barcode Reader
09 Front Panel
0A IP
0B Diagnostic
0C Error
0D Code Update
